規格與選配
頻率與量測效能
| 頻率範圍 | 100 kHz–20 GHz |
|---|---|
| 測試埠 | 2 埠或 4 埠,依機型配置 |
| 動態範圍(100 MHz–6 GHz) | >125 dB;典型值 135 dB。10 Hz 量測頻寬、未進行系統誤差修正,埠 1–2 或 3–4。 |
| 動態範圍(6–20 GHz) | >120 dB;典型值 130 dB,條件同上。 |
| 量測頻寬 | 1 Hz–1 MHz;選配可提高至 10 MHz。 |
量測與操作
| 量測項目 | 主動/被動 RF 元件的反射與傳輸 S 參數量測。 |
|---|---|
| 分析功能 | 混合模式 S 參數、嵌入/去嵌入與時域分析;擴充功能依授權及機型配置確認。 |
| 顯示與操作 | 12.1 吋彩色觸控螢幕、可顯示多組量測曲線。 |
| 校正 | 支援手動校正及自動校正單元;方法與配件依測試接頭及應用確認。 |
英文技術說明
Rohde & Schwarz presents the new midrange R&S ZNB20 vector network analyzers for frequency ranges from 100 kHz to 20 GHz.
These powerful analyzers are equipped with two test ports and offer outstanding measurement characteristics that are on a similar level as high-end instruments.
A dynamic range of up to 135 dB makes the new instruments perfect for tasks such as performing measurements on high-blocking DUTs such as filters.
The R&S ZNB20 offers a large dynamic range even at its start frequency of 100 kHz.
This makes it possible to perform precise measurements on wideband DUTs or components whose behavior at low frequencies is especially important.
The measurement time of only 5 ms with 401 points delivers high throughput in production.
The broad electronic control range of the output level up to 70 dB allows quick analysis of the small and large signal behavior of active components.
The large selection of calibration methods ensures that users are always able to make the right choice for the specific application.
The new R&S ZNB vector network analyzers have a touchscreen for intuitive, convenient operation.
The advanced operating concept featuring a very flat menu structure helps users find the necessary instrument functions in no more than three steps.
The 30 cm (12.1") screen is the largest of all network analyzers on the market, offering plenty of room for a clear display of the measurement results.
